Heavy Duty Hydraulic Mud Gun For Oil Drilling Solids Control System

Heavy Duty Hydraulic Mud Gun For Oil Drilling Solids Control System

Heavy Duty Hydraulic Mud Gun For Oil Drilling Solids Control System

Brand Name: TR Solids Control
Model Number: TRNJQ
MOQ: 1
Detail Information
Product Description
Detail Information
Place of Origin:
Xi'an,China
Certification:
APIQ1,ISO 9001
Diameter:
80mm
Work Pressure:
≤3.2Pma
Nozzle Number:
1/3e
Rotation:
360°
Highlight:

heavy duty hydraulic mud gun

,

oil drilling mud cleaning system

,

solids control hydraulic equipment

Product Description

Heavy Duty Hydraulic Mud Gun For Oil Drilling Solids Control System


Description


This professional solids control mud gun features high-strength anticorrosive structure and wear-resistant

nozzle, with flexible rotation and stable high-pressure jet effect. It effectively prevents sediment deposition,

keeps drilling mud well blended and maintains steady fluid performance. Suitable for oilfield mud tanks

and compatible with various solid control equipment. Durable, easy to install and maintain, it runs reliably

under harsh working environments.


Specific Applications


  1. Remove sand sediment at the bottom of mud tank
  2. Mix drilling fluid evenly to keep stable density and viscosity
  3. Flush blind areas inside the mud compartment
  4. Assist mud circulation and fluid transfer between cabinsPrevent solid particle settlement and equipment blockage


Technical parameter


Model

TRNJQ-3

TRNJQ-3X

TRNJQ80-3

TRNJQ80-3X

Diameter

50mm

50mm

80mm

80mm

Work Pressure

≤6.4Mpa

≤3.2Mpa

≤6.4Mpa

≤3.2Mpa

Nozzle Number

1/3e

Rotation Angle

N/A

360°

N/A

360°
